Machine working weight 800kg Engine brand Runtong
Bucket capacity 0.054m³ engine model V13-25C44
Walking speed low/high 0-1.8Km/h Maximum horsepower 25ps
Gdeability 15% Maximum power 18.4kw
Maximum digging radius 3695mm Maximum speed 2800rpm
Maximum digging depth 2260mm Displacement 1.267cc
Maximum digging height 2540mm Number of cylinders 3
Maximum unloading height 1876mm cooling metho water cooling
Transport length 3450mm Track (bandwidth * pitch * number of sections) 180*72*37
Transport width 1400mm Fuel tank 15.9L
Transport height with canopy 2250mm Hydraulic oil tank 21.6L
Upper plate ground clearance 410mm Travel hydraulic motor type: 612-4174-1
Bucket width 500mm Walking motor brand: EATON
Bulldozing board width 1300mm Motor displacement: 420cc
Main pump type/model TFA10V028LADS/53R Rotary hydraulic motor type: SW2.5K-245
Main pump brand TAIFENG Dsplacement: 251
